Molecular identification of three entomopathogenic fungi infecting the brown plant hopper pest in Indonesia
Egyptian Journal of Biological Pest Control volume 31, Article number: 62 (2021)
Brown plant hopper (Nilaparvata lugens Stal.) a very damaging pest to rice crops. One of the efforts to control it is the use of entomopathogenic fungi (EPF). Three fungal local isolates found in Indonesia were effective in controlling the brown plant hopper pest. This study aimed to molecularly identify the 3 fungal isolates. Molecular identification is very important to get the exact identity of these fungi. The accuracy of EPF identification will greatly determine the success of control. Molecular identification is based on a partial genetic analysis of the internal transcribed spacer (ITS) locus of ribosomal fungal DNA.
Morphology of the local isolates named J22 and J60 were identified as Paecilomyces sp., while the isolate J34 was identified as Beauveria sp. The results of molecular identification of the isolates J22 and J60 were identified as the fungi Lecanicillium saksenae and Simplicillium sp., while isolate J34 was identified as Myrothecium sp. The results of literature search showed that the 3 fungi have never been previously reported to infect the brown plant hopper.
In Indonesia, 3 types of EPF, namely L. saksenae, Simplicillium sp., and Myrothecium sp., were found having the potential to control the brown plant hopper pest.
Brown planthopper (BPH) Nilaparvata lugens is a major insect pest of rice that causes 20–80% yield loss through direct and indirect damage. The typical damage caused by BPH is drying of plants as if burning (hopperburn) (Balachiranjeevi et al. 2019). BPH can also transmit grassy stunt and ragged stunt viruses (Helina et al. 2019).
The frequency of BPH infestation is increasing frequently in developing Asian countries due to the killing of its natural enemies because of the use of synthetic chemical insecticides (Minarni et al. 2018). Entomopathogenic fungi (EPF) are fungi that can infect and kill insects (Litwin et al. 2020). The EPF that have been widely researched and known to be effective for controlling BPH pests are B. bassiana (Sumikarsih et al. 2019) and Metarhizium sp. (Chinniah et al. 2016). However, in their implementation in the field, the use of EPF to control BPH pests still has many weaknesses. After application in the field, insect pathogens are exposed to various abiotic stresses such as temperature and humidity (Hsia et al. 2014), UV radiation (Shafighi et al. 2014), and edaphic factors (Klingen et al. 2015).
In addition to biotic stress, the effectiveness of EPF in controlling insect pests is influenced by the diversity of varieties or strains or types of them. EPF have large genetic variations among different isolates. The pathogenicity, virulence, enzymatic characteristics, and DNA also varied among different isolates of different insects. The origin of the isolate affects the virulence diversity of the fungus against the host insect, due to the type or race or strain of the fungus (Chen et al. 2017a, b).
The results of previous studies have reported 3 effective fungal isolates to control the brown plant hopper pest. The 3 isolates caused 70–80% mortality within 3.43–4.87 days. The 3 isolates were Pasir Kulon (J22), Cipete (J34), and Papringan (J60). According to morphological characteristics, isolates J22 (Pasir Kulon) and J60 (Papringan) were identified as Paecilomyces sp., while J34 (Cipete) isolate was identified as Beauveria sp. (Minarni et al. 2020).
Accuracy of identification is very important in the use of EPF for insect pest control. Identification based on morphological characters cannot be used to distinguish fungi to the species level so it is necessary to identify them molecularly (Imoulan et al. 2017). This research aimed to precisely identify the 3 previously mentioned EPF isolates that attack the brown plant hoppers.
Fungal isolates J22 (Pasir Kulon), J34 (Cipete), and J60 (Papringan) were identified molecularly based on a partial genetic analysis on the internal transcribed spacer (ITS) locus of ribosomal DNA of fungi. Fungal isolates that will be identified previously were grown in potato dextrose broth (PDB) liquid media. After being incubated for 72 h, the fungal mycelia were harvested, using sterile filter paper and washed with sterile distilled water. The fungal mycelia were crushed in a sterile mortar by a sterile grinder and liquid nitrogen was added. Half a gram of dry fungal biomass was transferred to a 1.5-ml micro-tube containing 600 μl of cetyl trimethylammonium bromide (CTAB) buffer solution. Afterwards, the tube was shaken out and incubated at 65 °C for 30 min, then incubated in ice for 5 min. A mixture of chloroform and isoamyl alcohol with a ratio of 24:1 of 600 μl was added to the tube. The tubes were then centrifuged at 4 °C for 10 min at a speed of 25,000×g. The supernatant was transferred to a new tube and added with 0.1× volume of 2M NaOAc pH 5.2 and 3× volume of ethanol then incubated at − 20 °C for 2 h.
Fungal DNA pellets were obtained by centrifugation at 25,000×g at 4 °C for 25 min. The fungal DNA pellets were washed by 500 μl of 70% ethanol, then centrifuged at 25,000×g at 4 °C for 5 min. The fungal DNA pellets were dried in an airtight chamber for 5 min, then dissolved in 0.2× volume of RNAse and 30 μl of sterile TE (TrisHCl 10 mM, pH 7.4, EDTA 1 mM) buffer and then incubated at 37 °C for 10 min and 70 °C for 10 min.
Extraction of fungal DNA was done using Nucleon PhytoPure reagent kit (Amersham LIFE SCIENCE, USA). PCR amplification was at ITS, using ITS Primer 4: 5′-TCC TCC GCT TAT TGA TAT GC-3′ and ITS Primer 5: 5′-GGA AGT AAA AGT CGT AAC AAG G-3′ (White et al. 1990). DNA amplification was carried out by making a volume of 30 μl containing 10.5 μl of alkaline free water, 15 μl 2× PCR mastermix (Promega), 0.75 μl and 10 pmol respectively of primer ITS 4 and ITS 5 and 3 μl (about 250 ng/μl) DNA template. The amplification reaction was carried out in 35 cycles as follows: pre-denaturation at 95 °C for 15 min, denaturation at 95 °C for 30 min, heating (annealing) at 55 °C for 30 s, lengthening at 72 °C for 1.5 min, re-extension at 72 °C for 5 min. and lastly stored at 25 °C for 10 min.
Purification of PCR products was carried out by using Polyethilen Glycol (PEG) precipitation method (Hiraishi et al. 1995) and continued with a sequencing cycle. The results of sequencing cycle were purified again, using the ethanol purification method. Analysis of nitrogen base sequence readings was done using an automated DNA sequencer (ABI PRISM 3130 Genetic Analyzer) (Applied Biosystems). The raw data resulting from the sequencing was then trimmed and assembled, using the BioEdit program (http://www.mbio.ncsu.edu/BioEdit/bioedit.html). Sequence data that was assembled was then carried out in BLAST with genomic data that was registered at the National Center for Biotechnology Information (http://www.ncbi.nlm.nih.gov/BLAST) to determine taxon or species that have the greatest homology/similarity and molecularly.
Fungal isolates, isolated from brown plant hoppers, were infected by EPF. Fungi were purified and cultured on potato dextrose agar (PDA) media. The results of the observation on morphological characteristics, the isolates J22 (Pasir Kulon) and J60 (Papringan) were identified as Paecilomyces sp. while J34 (Cipete) isolate was identified as Beauveria sp. (Minarni et al. 2020). The morphological characters of each EPF isolate (J22, J34 and J60) are presented in (Table 1 and Figs. 1, 2, and 3).
The results of the ITS rDNA sequencing of fungal isolates J22, J34, and J60 are as follows:
ITS rDNA isolate sequence
Based on the results of the sequences, isolate J22 showed (99.83%) similarity to the L. saksenae strains GFRS14 and L. saksenae isolate Ecu121. Isolate J35 had a similarity with the sequences Myrothecium sp. F129 and Myrothecium sp. 1 TMS-2011 amounted to 98.82 and 98.93%, while isolate J60 had 99.10% similarities to the sequence Simplicillium sp. LCM 845.01 and 98.92% with Simplicillium sp. KYK00024 sequence (Table 2).
EPF isolates that showed high phylogenetic relationship and had a similarity value of 28S rDNA sequence of more than 99% with the reference species that could be expressed as one species. Ribosomal DNA sequences are used to identify and determine the phylogenetic relationships of organisms to taxa species (Bich et al. 2021). Based on the concept of phylogenetic species, it is stated that an organism is in one species when the difference in DNA sequences is between 0.2 and 1% (Shenoy et al. 2007). According to Henry et al. (2000) isolates, which have a similarity value of 100% can be stated as the same strain and a similarity value of 99% is stated as the same species, while the similarity value of 89–99% belongs to the same genus.
The similarity between 99 and 100% indicated that isolates J22, J34, and J60 each had the same chromosome number, genome size, and gene function as L. saksenae strain GFRS14 and L. saksenae strains isolate Ecu121, Myrothecium sp. F129, and Myrothecium sp. 1 TMS-2011 and Simplicillium sp. LCM 845.01 and Simplicillium sp. KYK00024, respectively.
The identification results based on morphological characters turned out to be different from molecular identification. Accuracy of identification is very important in the use of EPF for insect pest control. Identification based on morphological characters cannot be used as a definite reference. The genera Lecanicillium, Simplicillium, Beauveria, and Isaria have similar morphological characters, so that molecular identification is needed to determine the species certainty of EPF found in Banyumas Regency, Central Java Province, Indonesia. According to Lim et al. (2014) of the genus Lecanicillium, Simplicillium (both previously Verticillium spp.), Beauveria and Isaria belong to family Cordycipitaceae. According to Chen et al. (2016), the genus Myrothecium belongs to family Stachybotryaceae and has a worldwide distribution. Species in this genus were previously classified based on the asexual morphology, especially the characters of conidia and conidiophores. Morphology-based identification alone is imprecise because there are few characters to distinguish between species in the genus and, therefore, molecular sequence data are important in species identification.
Simplicillium sp. is one of the dominant genera of symbiont fungi in unfertilized brown planthopper eggs. The other 3 genera are Microdochium, Fusarium, and Cladosporium (Shentu et al. 2020). One of the species of the genus Simplicillium is S. lanosoniveum. The fungi belong to this genus are known as mycoparasites. However, silkworms (Bombyx mori) inoculated with the fungus isolate S. Lanosoniveum, died during the larval or pupal stage, as shown by the EPF, B. bassiana. The first report on the entomopathogenicity of S. lanosoniveum and demonstrated its potential for use in insect biological control was recorded by Lim et al. (2014). The fungus S. lanosoniveum was able to cause mortality of Hysteroneura setariae ticks on Plum plants by 86.33% (Chen et al. 2017a, b). Chen et al. (2019) found 3 new species, namely Simplicillium cicadellidae, S. formicidae, and S. lepidopterorum. So far, there are limited reports of the fungus Simplicillium sp. being isolated from insects infected with the fungus.
The fungus L. lecanii effectively controlled brown plant hoppers with a density of 1010 conidia/ml, where the mortality value of (78.33%) and a time of death at 5.81 day after treatment occurred (Khoiroh et al. 2014). L. lecanii can cause more than 50% of brown planthopper mortality within 14 days after treatment (Atta et al. 2020), whereas according to Shaikh and Pandurang (2015), this fungus is less effective in controlling this pest. Sankar and Rani (2018) have found a new Lecanicillium isolate, namely L. saksenae, which can control stink bug (Leptocorisa acuta). This fungus can kill 100% of L. acuta nymphs and imago at 72 h after treatment at conidia densities 107 and 108.
Myrothecium verrucaria has a high activity against extracellular insect cuticles and produces chitinase, proteinase, and lipase (Vidhate et al. 2015).
Based on the literature search, the 3 fungi Simplicillium sp., L. saksenae, and Myrothecium sp. have never been reported to infect brown plant hopper. Data obtained from the National Center for Biotechnology Information (https://www.ncbi.nlm.nih.gov/), also showed that these 3 fungi were not obtained from insect pests (Table 2). The results of this study revealed 3 types of new EPF that had the potential to be developed as control agents for brown plant hopper pests.
The results of molecular identification showed that the isolates J22, J34, and J 60 were fungi from L. saksenae, Myrothecium sp., and Simplicillium sp., respectively. The results of literature search showed that these 3 fungi had never been reported to infect brown plant hopper. So that the results of this study can be considered new finding of EPF as biological agents of the control brown plant hopper pests.
Availability of data and materials
All data are available in the article and the materials used in this work are of high quality and grade.
Brown plant hopper
Basic Local Alignment Search Tool
Cetyl trimethylammonium bromide
Internal transcribed spacer
Polymerase chain reaction
Potato dextrose agar
Potato dextrose broth
Atta B, Rizwan M, Sabir AM, Gogi MD, Farooq MA, Batta YA (2020) Efficacy of entomopathogenic fungi against brown planthopper Nilaparvata lugens (Stål) (Homoptera: Delphacidae) under controlled conditions. Gesunde Pflanzen 72(2):101–112. https://doi.org/10.1007/s10343-019-00490-6
Balachiranjeevi CH, Prahalada GD, Mahender A, Jamaloddin M, MAL S, Marfori-Nazarea CM, Vinarao R, Sushanto U, Baehaki SE, Li ZK, Ali J (2019) Identification of a novel locus, BPH38(t), conferring resistance to brown planthopper (Nilaparvata lugens Stal.) using early backcross population in rice (Oryza sativa L.). Euphytica 215(185):1–14. https://doi.org/10.1007/s10681-019-2506-2 (0123456789().,-volV)(0123456789().,-volV)
Bich GA, Castrillo ML, Kramer FL, Villalba LL, Zapata PD (2021) Morphological and molecular identification of entomopathogenic fungi from agricultural and forestry crops. Floresta e Ambiente 28(2):e20180086. https://doi.org/10.1590/2179-8087-FLORAM-2018-0086
Chen K, Li B, Lu Y, Zhang S, Wang C (2017b) Divergent LysM effectors contribute to the virulence of Beauveria bassiana by evasion of insect immune defences. Plos Pathog 13(9):e1006604. https://doi.org/10.1371/journal.ppat.1006604
Chen RS, Chi CH, Jia CL, Jwu GT (2017a) Evaluation of characteristics of Simplicillium lanosoniveum on pathogenicity to aphids and in vitro antifungal potency against plant pathogenic fungi. Int J Environ Agric Res (IJOEAR) 3(1):55–61. https://ijoear.com/Paper-January-2017/IJOEAR-JAN-2017-7.pdf.
Chen WH, Chang L, Yan FH, Jian DL, Wei YT, Zong QL (2019) Three novel insect-associated species of Simplicillium (Cordycipitaceae, Hypocreales) from Southwest China. MycoKeys 58:83–102. https://doi.org/10.3897/mycokeys.58.37176
Chen Y, Ran SF, Dai DQ, Wang Y, Hyde KD, Wu YM, Jiang YL (2016) Mycosphere essays 2. Myrothecium. Mycosphere 7(1):64–80. https://doi.org/10.5943/mycosphere/7/1/7
Chinniah C, Ravikumar A, Kalyanasundaram M, Parthiban P (2016) Field evaluation of Metarhizium anisopliae liquid formulation (BioMagic®) against brown plant hopper, Nilaparvata lugens Stal on rice. J Biopesticides 9(2):211–219 http://www.jbiopest.com/users/LW8/efiles/vol_9_2_211-219.pdf
Dong T, Zhang B, Jiang Y, Hu Q (2016) Isolation and classification of fungal whitefly entomopathogens from soils of Qinghai-Tibet Plateau and Gansu Corridorin China. Plos One 11(5):e 0156087. https://doi.org/10.1371/journal.pone.0156087
Helina S, Sulandari S, Hartono S, Trisyono YA (2019) Detection and analysis of protein profile on rice infected by stunting virus with different severity on ciherang and situ bagendit varieties. J Perlindungan Tanaman Indones 23(1):116–124. https://doi.org/10.22146/jpti.36549
Henry T, Iwen PC, Hinrichs SH (2000) Identification of Aspergillus species using internal transcribed spacer regions 1 and 2. J Clin Microbiol. 38(4):1510–1515. https://doi.org/10.1128/JCM.38.4.1510-1515.2000
Hiraishi A, Kamagata Y, Nakamura K (1995) Polymerase chain reaction amplification and restriction fragment length polymorphism analysis of 16S rRNA genes from methanogens. J Ferment Bioeng. 79(6):523–529. https://doi.org/10.1016/0922-338x(95)94742-A
Hsia ICC, Islam MT, Ibrahim Y, How TY, Omar D (2014) Evaluation of conidial viability of entomopathogenic fungi as influenced by temperature and additive. Int J Agric Biol. 16(1):146–152 http://www.fspublishers.org
Imoulan A, Hussain M, Kirk PM, El Meziane A, Yao YJ (2017) Entomopathogenic fungus Beauveria: host specificity, ecology and significance of morpho-molecular characterization in accurate taxonomic classification. J Asia-Pac Entomol 20(4(4):1204–1212. https://doi.org/10.1016/j.aspen.2017.08.015
Khoiroh F, Isnawati, Ulfi F (2014) Patogenitas cendawan entomopatogen (Lecanicillium lecanii) sebagai bioinsektisida untuk pengendalian hama wereng batang coklat secara in vivo. Lentera Bio. 3(2):115–121 http://ejournal.unesa.ac.id/index.php/lenterabio
Klingen I, Westrum K, Meyling NV (2015) Effect of Norwegian entomopathogenic fungal isolates against Otiorhynchus sulcatus larvae at low temperatures and persistence in strawberry rhizospheres. Biol Control 81:1–7. https://doi.org/10.1016/j.biocontrol.2014.10.006
Lim SY, Lee S, Kong HG, Lee J (2014) Entomopathogenicity of Simplicillium lanosoniveum Isolated in Korea. Mycobiology 42(4):317–321. https://doi.org/10.5941/MYCO.2014.42.4.317
Litwin A, Nowak M, Rozalska S (2020) Entomopathogenic fungi: unconventional applications. Rev Environ Sci BioTechnol 19(1):23–42. https://doi.org/10.1007/s11157-020-09525-1
Minarni EW, Soesanto L, Suyanto A, Rostaman (2020) Exploration and pathogenicity test of entomopathogenic fungus from brown planthopper (Nilaparvata lugens Stal) pest. Eco Env Cons. 26(1):24–33 http://www.envirobiotechjournals.com/EEC/26Issue12020/EEC26-4.pdf
Minarni EW, Suyanto A, Kartini K (2018) Potensi parasitoid telur dalam mengendalikan WBC (Nilaparvata lugens Stal.) pasca ledakan populasi di Kabupaten Banyumas. Jurnal Perlindungan Tanaman Indones 22(2):132–142. https://doi.org/10.22146/jpti.28886
Nguyen HC, Thi VAT, Quoc LN, Nhu NN, Minh KN, Ngoc TTN, Chia HS, Kuang HL (2017) Newly isolate Paecilomyces lilacinus and Paecilomyces javanicus as novel biocontrol agents for Plutella xylostella and Spodoptera litura. Not Bot Horti Agrobo 45(1):280–286. https://doi.org/10.15835/nbha45110726
Nuraida A, Hasyim A (2009) Isolasi, identifikasi, dan karakterisasi jamur entomopatogen dari rizosfir pertanaman kubis. J Hort. 19(4):419–432 http://ejurnal.litbang.pertanian.go.id/index.php/jhort/article/view/868
Rosmini R, Lasmini SA (2010) Identifikasi cendawan entomopatogen lokal dan tingkat patogenitasnya terhadap hama wereng hijau (Nephotettix virescens distant.) vektor virus tungro pada tanaman padi sawah di Kabupaten Donggala. J Agroland 17(3):205–212. https://doi.org/10.22487/J.24077607.2010.v17.i3.304
Sankar SSH, Rani OPR (2018) Pathogenicity and field efficacy of the entomopathogenic fungus, Lecanicillium saksenae Kushwaha, Kurihara and Sukarno in the management of rice bug, Leptocorisa acuta Thunberg. J Biol Control 32(4):230–238. https://doi.org/10.18311/jbc/2018/19808
Shafighi Y, Ziaee M, Ghosta Y (2014) Diatomaceous earth used against insect pests, applied alone or in combination with Metarhizium anisopliae and Beauveria bassiana. J Plant Prot Res 54(1):62–66. https://doi.org/10.2478/jppr-2014-0009
Shaikh SH, Pandurang M (2015) Effect of entomopathogenic fungi against brown plant hopper, Nilaparvata lugens (Stal.) (Hemiptera: Delphacidae) infesting rice. Int J Sci Res (IJSR) 4(10):905–907 http://www.ijsr.net
Shenoy BD, Jeewon R, Hyde KD (2007) Impact of DNA sequence-data on the taxonomy of anamorphic fungi. Fungal Divers 26:1–54 https://www.fungaldiversity.org/fdp/sfdp/26-1.pdf
Shentu X, Xiao Y, Song Y, Chao Z, Fun J, Yu X (2020) Comparative analysis of the diversity of the microbial communities between non-fertilized and fertilized eggs of brown planthopper, Nilaparvata lugens. Insects 11(1):49; (1-13). https://doi.org/10.3390/insects11010049
Sumikarsih E, Herlinda S, Pujiastuti Y (2019) Conidial density and viability of Beauveria bassiana isolates from Java and Sumatra and their virulence against Nilaparvata lugens at different temperatures. AGRIVITA. J Agric Sci 41(2):335–350. https://doi.org/10.17503/agrivita.v41i2.2105
Vidhate R, Jyoti S, Vandana G, Santosh BC, Amar P, Mukund VD (2015) Use of hydrolytic enzymes of Myrothecium verrucaria and Conidia of Metarhizium anisopliae, singly and sequentially to control pest and pathogens in grapes and their compatibility with pesticides used in the field. Biopestic Int. 11(1):48–60 https://www.researchgate.net/publication/282292037
White TJ, Bruns TD, Lee SB, Taylor JW (1990) Amplification and direct sequencing of fungal RNA genes for phylogenetics. In: Innis MA, Gelfand DH, Sninsky JJ, White TJ (eds) PCR protocols. Academic, San Diego, pp 315–322
The author would like to thank the Head of the Laboratory of Plant Protection, Faculty of Agriculture, Jenderal Soedirman Purwokerto University, The Biology Laboratory of Indonesian Academy of Sciences, and all those who have helped research and write this scientific article.
The author would like to thank the Directorate of Research and Community Service of the Ministry of Education and Culture of the Republic of Indonesia for funding this research through the Doctoral Dissertation Research Grant in 2020.
Ethics approval and consent to participate
Consent for publication
The authors declare that they have no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Minarni, E.W., Soesanto, L., Suyanto, A. et al. Molecular identification of three entomopathogenic fungi infecting the brown plant hopper pest in Indonesia. Egypt J Biol Pest Control 31, 62 (2021). https://doi.org/10.1186/s41938-021-00412-7
- Entomopathogenic fungus
- Lecanicillium saksenae
- Molecular identification
- Myrothecium sp.
- Nilaparvata lugens
- Simplicillium sp.
- Brown plant hopper
