First record of Diaeretus leucopterus (Haliday) (Hymenoptera, Braconidae, Aphidiinae), the parasitoid of the aphid species, Eulachnus agilis (Kaltenbach) (Hemiptera, Aphididae) in North Africa

Abstract

A survey of pine-associated aphids and their parasitoids was carried out in the arboretum of Pinus halepensis Miller in the Higher Agronomic Institute Chott Mariem (ISA CM, Tunisia) during 2010–2011 and 2018. The survey revealed the presence of the aphid parasitoid species, Diaeretus leucopterus (Haliday) (Hymenoptera, Braconidae, Aphidiinae). This is the first record of D. leucopterus from Tunisia and the African continent. The parasitoid emerged from the spotted green pine needle aphid, Eulachnus agilis (Kaltenbach) (Hemiptera, Aphididae, Lachninae), on P. halepensis. The generalist hyperparasitoid, Asaphes suspensus (Nees) (Hymenoptera, Pteromalidae), was also found attacking D. leucopterus. The diagnosis of the primary parasitoid, on the basis of relevant illustrations, was provided, and the possible routes of its transportation into North Africa were discussed.

Background

Pinus spp. are the largest genus of the coniferous plants in the northern hemisphere. They include many important species from the economic and ecologic point of views (Gernandt et al. 2005). Three pine tree species are common in Tunisia, including the Aleppo pine, Pinus halepensis Miller; the maritime pine, P. pinaster Aiton; and the stone pine, P. pinea L. The first two species are naturally grown in a wide area of Tunisia. P. halepensis consists of the main forest element of Tunisia that encompasses about 297,000 ha, i.e., 57% of the total forest area of the country (Khouja 1997). P. pinea forests are found along the coasts of Tunisia, in about 27,000 ha, after plantation of dunes between Tabarka and Kelibia.

Although several insect species are associated with the pine forests globally, some of them have been primarily raised as economic pests. Aphids of the genus Eulachnus del Guercio (Hemiptera, Aphididae, Lachninae) have a significant anti-aesthetic impact on the urban areas, where pine species are grown as ornamental and shading plants (Morris 2006). Eulachnus aphids are widely distributed outside their original sources, due to the massive transportation of infested pine stock through international trade (Richardson 1998). Although Eulachnus spp. have a Palaearctic origin, 3 species (Eulachnus agilis (Kaltenbach), E. brevipilosus Börner, and E. rileyi (Williams)) have invaded North and South America (Blackman and Eastop 1994). The majority of these aphids are effectively controlled in their native areas of distribution mainly due to the activity of their natural enemies. However, they become important pests in the absence of their natural enemies in the areas of invasion. Therefore, once established, they cause serious damages to seedling and mature pine trees (Alford 2012).

Four Eulachuns species, i.e., E. agilis, E. nigricola (Pašek) (Ben Halima Kamel 2012; Kanturski et al. 2017), E. rileyi (Boukhris-Bouhachem et al. 2007), and E. tuberculostemmatus (Theobald) (Ben Halima Kamel et al. 2019) have been recorded in Tunisia. Although the complex of natural enemies of Eulachnus spp. is well studied in the Mediterranean countries (Núñez-Pérez and Tizado 1996; Kavallieratos et al. 2004), there are no data from Tunisia and other North African countries. Till now, only generalist coccinellids have been recorded that associated with Eulachnus spp. in this region (Ben Halima Kamel et al. 2018).

In the present study and through a survey of the pine-associated aphids and their parasitoids carried out in Tunisia, the aphid parasitoid species, Diaeretus leucopterus (Haliday) (Hymenoptera, Braconidae, Aphidiinae), was recorded for the first time. Its diagnosis and the possible routes of its transportation into North Africa were discussed.

Material and methods

The materials were collected from the arboretum of P. halepensis in the Higher Agronomic Institute Chott Mariem (ISA CM, Tunisia) during spring (2010, 2011, 2018). Pine needles were inspected in situ for aphid colonies (Eulachnus spp.). Once detected, needles, that carried aphids, were carefully cut off and subdivided into plastic boxes with a dimension of 100 × 150 mm. Subsequently, boxes were covered by muslin to allow ventilation of the content. Few adult aphids were separately preserved in 70% ethanol for later identification. The collected materials were maintained for 2–3 weeks under laboratory conditions at 25 °C and inspected daily for the emergence of adult parasitoids. The remaining material was kept for 2 additional weeks at the same conditions to rear any secondary parasitoids. The emerged parasitoids were carefully captured, using an aspirator and dropped into 75% ethanol. Female parasitoids were dissected and slide-mounted in the Hoyer medium. The slide specimens were studied under a Nikon® Eclipse E200 microscope (Nikon Corporation, Japan). Photos from the slides were captured by a Canon® EOS 700D camera (Canon Inc., Japan) and used to prepare line drawings in the Adobe® Illustrator CS5. A card-mounted specimen was imaged by using the Canon® EOS 700D, mounted with an adapter on Hund® stereomicroscope (Wetzlar Inc., Germany). A series of 10–15 multi-focused captured photographs were subsequently merged into a single in-focus image by using the Zerene Stacker version 1.04 software (Zerene Systems LLC, 2017). The morphological terminology used in this study follows that of Sharkey and Wharton (1997) for parasitoids and Blackman and Eastop (2016) for aphids. Parasitoid specimens are deposited in the collection of the Department of Plant Protection, University of Zabol (DPPZ), Iran.

Results and discussion

The aphid parasitoid species D. leucopterus emerged from mummies of E. agilis.

Taxonomic account

Order: Hymenoptera Linnaeus, 1758

Family: Braconidae Nees, 1811

Subfamily: Aphidiinae Haliday, 1833

Diaeretus leucopterus (Haliday, 1834)

Aphidius leucopterus Haliday, 1834. Entomological Magazine, 2:93–106.

Material examined: 3♀ 1♂, ex. Eulachnus agilis (Kaltenbach), on Pinus halepensis Miller, during April 2010, 2011, and 2018, Tunisia, ISA CM (35° 54′ 58″ N, 10° 33′ 36″ E).

Diagnosis: (female—Fig. 1). Body length 1.7–1.9 mm. Head sparsely setose, wider than thorax at tegula. Eyes medium sized. Malar space 0.25–0.30 times longitudinal eye diameter. Tentorial index 0.6–0.7. Clypeus flat, with 4–6 long setae. Maxillary palpi four-segmented, labial palpi 2-segmented. Antenna filiform, 16-segmented. Mesoscutum (Fig. 2a) smooth and shiny with rows of sparse setae along the trace of effaced notaulices. Forewing (Fig. 2b) stigma triangular, its length 2.4–2.6 times its maximum width, and 1.9–2.1 times R1. Vein r&RS short, not reaching the end of stigma, its length 0.85–0.95 times R1. Propodeum (Fig. 2c) smooth with the anterolateral and central carinae which extended near the spiracles. Petiole (Fig. 2d) stout, slightly constricted after spiracles, then parallel sided, 3 times its width at spiracles. Gaster lanceolate. Ovipositor sheath (Fig. 2e) stout, sub quadrate and apically truncated. Recorded diagnostic characters agree with that reported by Kaliuzhna (2014).

Fig. 1
figure1

Diaeretus leucopterus (Haliday), female, lateral aspect of habitus

Fig. 2
figure2

Diaeretus leucopterus (Haliday), female. a Mesonotum, dorsal aspect. b Forewing. c Propodeum, dorsal aspect. d Petiole, dorsal aspect. e Genitalia, lateral aspect. (After Rakhshani et al. 2019)

Coloration: Generally dark, head and mesosoma black, gaster dark brown. Antenna brown, with dark brown scape and pedicel. Legs light brown with yellow patches at tip of segments. Mummified aphids of yellowish brown color were mainly attached to the underside of the needles (Figs. 3a, b). Parasitoids were emerged 7 days post-collection by cutting a circular hole at the posterior part of the mummy above the cauda (Fig. 3c).

Fig. 3
figure3

Parasitized individuals of Eulachnus agilis (Kaltenbach). a, b Matured mummified aphid parasitized by Diaeretus leucopterus (Haliday). c Mummified aphid with emergence hole by the adult parasitoid at the postero-dorsal area. d Emergence hole of a hyperparasitoid, Asaphes suspensus (Nees), at the anterio-dorsal area of the mummy

The hyperparasitoid Asaphes suspensus (Nees) (Hymenoptera, Pteromalidae) was also emerged from the mummified aphids (2♀ 3♂, same data as for the parasitoid, April 2010 and 2011). This species was already recorded in North Africa in Morocco (Vago 2002). It is a generalist hyperparasitoid of numerous aphid species excluding pine aphids (Gibson and Vikberg 1998). The emergence hole of the adult hyperparasitoid, with irregular margines, is distinctly smaller than the corresponding hole of the primary parasitoid and cutted at the anterio-dorsal area of the mummy (Fig. 3d). Another species, Asaphes vulgaris Walker (Hymenoptera, Pteromalidae), was also recorded as a hyperaprasitoid of D. leucopterus via E. rileyi (Suay Cano et al. 1998). Further records regarding the associations of the generalist hyperparasitoids of the genus Dendrocerus Ratzeburg (Hymenoptera, Megaspilidae) with D. leucopterus, both in Eastern (Takada 1973) and Western (Starý 1977) Palaearctics, indicate the presence of diverse food webs rooted on Eulachnus spp. to be explored by subsequent studies.

Diaeretus leucopterus was recorded for the first time not only in Tunisia but also in the African continent in association with E. agilis on P. halepensis. Diaeretus leucopterus is a widely distributed species in the Western Palaearctic, including some European countries (Mackauer and Starý 1967; Kavallieratos et al. 2004; Kaliuzhna 2014) and some countries of the Eastern Palaearctic (Starý and Schlinger 1967; Takada 1968; Chen and Shi 2001; Starý et al. 2010) or Oriental (Starý and Ghosh 1983). Several Mediterranean countries, including France, Greece, and Italy, have been recorded as common areas of distribution of D. leucopterus, from where it might be accidentally introduced into the North African area (Tunisia). According to Sghaier and Claustriaux (2015), P. halepensis is of mixed origin since some P. halepensis forests are assumed to originate from the nearby countries, i.e., Africa (Morocco), Southern Europe (Italy), and Western Asia (Israel).

Siphonatrophia cupressi (Swain) (Hemiptera, Aphididae, Aphidinae) has been recently recorded in Tunisia on Cupressus sempervirens L. parasitized by an unknown parasitoid species (Ben Halima Kamel and Mdellel 2017). Since both aphids (E. agilis and S. cupressi) and their host plants (P. halepensis, C. sempervirens) were found in the same area (ISA CM), the association of D. leucopterus with S. cupressi seems expectable. It should be noted that the 2 aphid genera, Eulachnus and Schizolachnus Mordvilko (Hemiptera, Aphididae, Lachninae), were recorded as hosts of D. leucopterus in the Mediterranean area (Kavallieratos et al. 2004). However, further field efforts are necessary to confirm this hypothesis. Few host records of D. leucopterus including Mindarus abietinus Koch (Hemiptera, Aphididae, Mindarinae) (Čapek 1960) and Brachycaudus cardui (L.) (Hemiptera, Aphididae, Aphidinae) (Fulmek 1968) look doubtful and need verification. Although some other coniferous-associated aphid species, mainly of the genus Cinara Curtis are present in Tunisia (Ben Halima Kamel 2012; Ben Halima Kamel et al. 2019), they have not been found parasitized yet (Rakhshani et al. 2019). One other European parasitoid of Eulachnus aphids, Praon bicolor Mackauer (Hymenoptera, Braconidae, Aphidiinae) (Kavallieratos et al. 2004), was found in the Mediterranean counties (Tremblay 1975; Núñez-Perez and Tizado 1996). It is an uncommon species, while its occurrence in North Africa has not been documented yet. The Nearctic aphids of the genus Essigella del Guercio are biogeographically associated with pine trees in North America (Blackman and Eastop 1994; Théry et al. 2018). Diaeretus essigellae Starý & Zuparko (Hymenoptera, Braconidae, Aphidiinae) was described from Essigella californica (Essig) (Hemiptera, Aphididae, Lachninae) on Pinus spp. in California (Starý and Zuparko 2002). It is closely related to D. leucopterus, but it is immediately separated by the absence of propodeal carinae. However, it is rather unlikely to occur in Tunisia, since pine seedlings are not transported from North America to Tunisia. A comparison of both Diaeretus species, using DNA sequences, can provide further data about the identity of these taxa and their associated host aphids.

Conclusion

Both Eulachnus aphids and their parasitoid, D. leucopterus, seem to be invasive species in North Africa (Tunisia). Considering the economic importance of these pest aphids, further investigation in the neighboring countries is needed to reveal the expansion of the parasitoid and to confirm its possible establishment.

Availability of data and materials

All the mentioned specimens are deposited in the DPPZ collection and are available.

Abbreviations

DPPZ:

Department of Plant Protection, University of Zabol

ISA CM:

Institut Supérieur Agronomique Chott Mériem

References

  1. Alford DV (2012) Pests of ornamental trees, shrubs and flowers: a color handbook, 2nd ed. CRC Press, London, UK. https://doi.org/10.1201/b15136

  2. Ben Halima Kamel M (2012) Aphid fauna (Hemiptera, Aphididae) and their host association of Chott Mariem, coastal area of Tunisia. Ann Biol Res 3:746–754

  3. Ben Halima Kamel M, Mdellel L (2017) Présence de Siphonatrophia cupressi (Hemiptera, Aphididae) en Tunisie. Bull OEPP/EPPO Bull 47:549–550 https://doi.org/10.1111/epp.12405

  4. Ben Halima Kamel M, Mdellel L, Zouari S, Adouani R (2018) Occurrence of Harmonia axyridis in Tunisia. Bull OEPP/EPPO Bull 48:307–308 https://doi.org/10.1111/epp.12473

    Article  Google Scholar

  5. Ben Halima Kamel M, Zouari S, Mdellel L, Rekik A (2019) Eulachnus tuberculostemmatus (Lachninae, Eulachnini) sur pin d’Alep: premier signalementen Tunisie. Bull OEPP/EPPO Bull 49:336–337 https://doi.org/10.1111/epp.12560

  6. Blackman RL, Eastop VF (1994) Aphids on the world’s trees: an identification and information guide. CAB International, Wallingford

    Google Scholar

  7. Blackman RL, Eastop VF (2016) Aphids on the world’s plants. An online information and information guide. Available via: http://www.aphidsonworldsplants.info.

  8. Boukhris-Bouhachem S, Souissi R, Turpeau E, Rouzé-Jouan J, Fahem M, Brahim NB, Hulle M (2007) Aphid (Hemiptera, Aphidoidea) diversity in Tunisia in relation to seed potato production. Ann Soc Entomol France 43:311–318 https://doi.org/10.1080/00379271.2007.10697526

  9. Čapek M (1960) Verzeichnis der Parasiten, die aus Schadinsekten an VULH in Banská Štiavnica gezogen wurden. Teil I. Wirte der Brackwespen - Braconidae (Hymenoptera). Ved práce Výsk úst lesn hosp, B Štiavnica 1:199–212. (in Slovak).

  10. Chen JH, Shi QX (2001) Systematic studies on Aphidiidae of China (Hymenoptera, Aphidiidae). Fujian Science and Technology Publishing House, Fujian (in Chinese)

  11. Fulmek L (1968) Parasitinsekten der Insektengallen Europas. Beitr Entomol 18:719–952

    Google Scholar

  12. Gernandt DS, Lopez GG, Garcia SO, Liston A (2005) Phylogeny and classification of Pinus. Taxon 54:29–42 https://doi.org/10.2307/25065300

    Article  Google Scholar

  13. Gibson GAP, Vikberg V (1998) The species of Asaphes Walker from America north of Mexico, with remarks on extralimital distributions of taxa (Hymenoptera, Chalcidoidea, Pteromalidae). J Hym Res 7:209–256 http://biostor.org/reference/522

  14. Kaliuzhna MO (2014) First records and comparative notes of twelve aphidiid species (Hymenoptera, Aphidiidae) from the fauna of Ukraine. Vestn Zool 48:387–400 https://doi.org/10.2478/vzoo-2014-0047

    Article  Google Scholar

  15. Kanturski M, Kajtoch L, Wieczorek K (2017) European species of the aphid genus Eulachnus Del Guercio, 1909 (Hemiptera, Aphididae, Lachninae): revision and molecular phylogeny. Zootaxa 4356:1–81 https://doi.org/10.11646/zootaxa.4356.1.1

  16. Kavallieratos NG, Tomanović Ž, Starý P, Athanassiou CG, Sarlis GP, Petrović O, Niketić M, Veroniki MA (2004) A survey of aphid parasitoids (Hymenoptera, Braconidae, Aphidiinae) of Southeastern Europe and their aphid-plant associations. Appl Entomol Zool 39:527–563 https://doi.org/10.1303/aez.2004.527

  17. Khouja ML (1997) Variabilité géographique du Pin d’Alepen Tunisie: perspectives d’amélioration de la productivité et de la qualité physique du bois. Université Catholique de Louvain-la-Neuve, Belgium, Ph.D Dissertation

    Google Scholar

  18. Mackauer M, Starý P (1967) Hymenoptera Ichneumonoidea: World Aphidiidae. In: Delucchi V, Remaudière G (eds) Index of Entomophagous Insects. Le Francois, Paris, pp 1–195

    Google Scholar

  19. Morris B (2006) Insects and human life. Berg Publishers, UK

    Google Scholar

  20. Núñez-Pérez E, Tizado EJ (1996) Conifer aphids (Homoptera, Aphididae) and some natural enemies in the León province (Spain). Bol Asoc Esp Entomol 20:85–93

  21. Rakhshani E, Barahoei H, Ahmad Z, Starý P, Ghafouri-Moghaddam M, Mehrparvar M, Kavallieratos NG, Čkrkić J, Tomanović Ž (2019) Review of Aphidiinae parasitoids (Hymenoptera, Braconidae) of the Middle East and North Africa: key to species and host associations. Eur J Taxonomy 552:1–132 https://doi.org/10.5852/ejt.2019.552

  22. Richardson DM (1998) Forestry trees as invasive aliens. Conserv Biol 12:18–26 https://doi.org/10.1046/j.1523-1739.1998.96392.x

    Article  Google Scholar

  23. Sghaier T, Claustriaux JJ (2015) Interaction provenances-environments du Pin d’Alep (Pinus halepensis Mill.) en Tunisie. Bull Séanc Acad R Sci Outre-Mer 61:437–451

    Google Scholar

  24. Sharkey MJ, Wharton RA (1997) Morphology and terminology. In: Wharton RA, Marsh PM, Sharkey MJ (eds.) Manual of the New World Genera of the Family Braconidae (Hymenoptera), International Society of Hymenopterists, Special Publication 1, Washington, DC., pp 19–37.

  25. Starý P (1977) Dendrocerus-hyperparasites of aphids in Czechoslovakia (Hymenoptera, Ceraphronoidea). Acta Entomol Bohem 74:1–9

    Google Scholar

  26. Starý P, Ghosh AK (1983) Aphid parasitoids of India and adjacent countries (Hymenoptera, Aphidiidae). Zool Sur India, Tech Monogr 7:1–96

  27. Starý P, Rakhshani E, Tomanović Ž, Kavallieratos NG, Sharkey M (2010) Aphid parasitoids (Hymenoptera, Braconidae, Aphidiinae) from Thailand. Zootaxa 2498:47–52 https://doi.org/10.11646/zootaxa.2498.1.3

    Article  Google Scholar

  28. Starý P, Schlinger ES (1967) A Revision of the Far East Asian Aphidiidae (Hymenoptera). Dr. W Junk, The Hague

    Book  Google Scholar

  29. Starý P, Zuparko RL (2002) Diaeretus essigellae (Hymenoptera, Braconidae), a new species parasitic on Essigella pine aphids (Homoptera, Aphididae) from California. Pan-Pac Entomol 78:56–61

  30. Suay Cano VA, Luna Martinez F, Michelena Saval JM (1998) Parasitoides no afidiinos de pulgones (Chalcidoidea, Aphelinidae) e hiperparasitoides de las superfamilias Chalcidoidea, Ceraphronoidea y Cynipoidea (Hymenoptera, Apocrita, parasitica) en la provincia de Valencia. Bol Asoc Esp Entomol 22:99–113

  31. Takada H (1968) Aphidiidae of Japan (Hymenoptera). Insecta Matsumurana 30:67–124

    Google Scholar

  32. Takada H (1973) Studies on aphid hyperparasites of Japan. I. Aphid hyperparasites of the genus Dendrocerus Ratzeburg occurring in Japan (Hymenoptera, Ceraphronidae). Insecta Matsumurana 2:1–37

  33. Théry T, Kanturski M, Favret C (2018) Molecular data and species diagnosis in Essigella Del Guercio, 1909 (Sternorrhyncha, Aphididae, Lachninae). ZooKeys 765:103–122 https://doi.org/10.3897/zookeys.765.24144

    Article  Google Scholar

  34. Tremblay E (1975) I parassiti degli afidi del Pinus nigra Arn. (Hymenoptera, Ichneumonoidea). Boll Lab Entomol Agr Portici 32:91–110

  35. Vago JL (2002) Contribution to the knowledge on Pteromalidae of Morocco, with description of two new species of the genus Pteromalus Swederus, 1795 (Hymenoptera, Chalcidoidea). Notes Faun Gembloux 44:95

    Google Scholar

  36. Zerene Systems LLC (2017). Zerene Stacker Pro Version 1.04, Build T201706041920 x64. Richland, WA, USA. Online available at: http://zerenesystems.com/cms/home

Download references

Acknowledgements

Our sincere thanks to Zahra Rahmani (Department of Plant Protection, University of Zabol) who kindly took the photograph of the parasitoid specimen.
