Heterorhadbitis indica SL0708 hermaphrodite and axenic egg isolation

Egyptian Journal of Biological Pest Control volume 29, Article number: 22 (2019) Cite this article

Abstract

In Colombia, Heterorhabditis indica SL0708 is an entomopathogenic nematode (EPN) used for effective biological control of insect pests. The purpose of this study was to standardize hermaphrodite and axenic egg extraction, in addition to describe egg developmental stages to optimize in vitro infective juvenile egg production for future pest control. Thus, the greater wax moth, Galleria mellonella L. (Lepidoptera: Pyralidae), in its last larval instar was dissected at 90, 95, 100, 105, 110, and 115 h post-infection. Hermaphrodites were counted and egg stage within the uterus was characterized. Fertilized H. indica SL0708 egg presented 9 developmental stages; stage 1: maternal pronucleus migrates to the posterior pole, forming pseudoclivage segmentation until reaching stage 9 with a moving J1 formed. At 95 h post-infection, the greatest number of hermaphrodites, at stage 9, was observed. Not all hermaphrodites presented the same number of eggs and stage of development within their uterus. Subsequently, a protocol to rupture hermaphrodites and sterilize eggs was evaluated, assaying three different exposure times and two egg incubation periods. A hermaphrodite exposure to 0.1 M NaOH and 1% NaOCl solution for 15 min to allow obtaining viable axenic eggs, facilitating laboratory tests with nematode H. indica SL0708 free of Photorhabdus luminescens SL0708 or other bacteria that could introduce variability in future assays was established.

Background

The entomopathogenic nematode, Heterorhabditis indica SL0708 is a eumetazoan, ecdysozoan protostomate, and an obligate and lethal parasite of insects, as a consequence of its symbiotic association with enteric bacteria that kill the insect host. Fertilization occurs in hermaphrodite adults, with sperm and eggs generated in the ovotestis. H. indica SL0708 is protoandrous, namely, sperm is produced before eggs, resulting in self-fertilization (Johnigk and Ehlers 1999a, b and Sáenz and Lopez 2011). Eggs are isolecithal, with sparse evenly distributed yolk. H. indica SL0708 exhibits rotational holoblastic egg cleavage, in an asymmetric fashion along the anterior-posterior axis, near of what is to become the posterior pole. During early cleavage, each asymmetrical division results in a large AB founder cell, with a smaller posterior stem cell of P1 lineage. During the second division, AB founder cell cleavage occurs equatorially, producing another EMS founder cell, while the stem cell divides meridionally to produce a posterior P2 stem cell (Skop and White 1998 and Gilbert, Gilbert F 2014). Following cleavage stages, a juvenile one (J1) results.

Axenic J1 is a developmental stage, used as an alternative to inoculate in vitro solid or liquid H. indica SL0708 production media, where P. luminescens subsp. akhurstii SL0708 bacterial symbiont was first added into the culture media (Salazar et al. 2017). Bacteria are transformed by the culture media and used as a source of nourishment for J1 (Lunau et al. 1993 and Ehlers 2001). Nevertheless, given the difficulty in recovering viable J1, generally in vitro production media inoculation processes use infective juvenile (IJ). However, if these IJ are not axenic, without superficial microorganisms or between their cuticles, changes in P. luminescens SL0708 concentration in the media makes standardization and process development more cumbersome. Presence of a microorganism different from the symbiont, such as Ochrobactrum spp., Providencia spp., and Paenibacillus spp., can reduce IJ production yield and/or inhibit the nematodes’ life cycle (Jackson et al. 1995; Boemare et al. 1996; Babic et al. 2000 and Enright and Griffin 2004).

Therefore, studies have been developed to determine protocols for axenic egg harvest, as described by Poinar JR G (1979), involving chemicals and antibiotics. Lunau et al. (1993) described two methodologies: alkaline lysis and surface sterilization for Steinernema and Heterorhabditis species. With this methodology, it was possible to obtain bacteria-free eggs, particularly of Steinernema genus. Later, Kaya and Stock (1997) described a protocol based on mechanical maceration and chemicals to rupture hermaphrodites. Recently, Susurluk et al. (2013) adapted and implemented the methodology described by Lunau et al. (1993) for Heterorhabditis bacteriophora isolated in Turkey to evaluate nematode quality produced in vitro.

Henceforth, this study standardized H. indica SL0708 hermaphrodite isolation to obtain axenic viable eggs followed by their development.

Materials and methods

Heterorhadbitis indica SL0708 hermaphrodite quantification and egg isolation

Last larval instar of Galleria mellonella L. (Lepidoptera: Pyralidae) larvae (n = 160) was infected in multi-well plates, inoculating 50 IJs/larvae and incubated at 26 °C for 90, 95, 100, 105, 110 and 115 h. For nematode development identification, 10 larvae were dissected at different post-infection time points to classify as egg, JI, J1, J2, J3, J4, hermaphrodite, adult hermaphrodite, Endotokia matricida, female, or male. For H. indica SL0708 egg development nine stages were recognized, with a stage 1 the least developed, identified as ruffling, and stage 9 was the most developed, with a formed and moving J1within the egg. Other stages were stage 2, pseudoclivage; stage 3, pronuclei fusion; stage 4, two cell formation; stage 5, initiation of four cell development; stage 6, four cell development; stage 7, gastrulation; and stage 8, morphogenesis.

To determine the total number of eggs and egg percentage at stage 9 within a hermaphrodite from 1 G. mellonella larva, 10 H. indica SL0708 hermaphrodites were isolated. Each hermaphrodite was individually macerated. From the obtained suspension, six 30 μl drops were obtained for egg quantification.

H. indica SL0708 J1 viable axenic egg isolation

Protocols from Lunau et al. (1993), Kaya and Stock (1997), and Susurluk et al. (2013) were implemented to obtain axenic eggs. Thirty hermaphrodites were exposed to 0.1 M NaOH and 1% NaClO for 5, 10, and 15 min, followed by 3-min centrifugation at 3000 rpm. The supernatant was discarded, and a dH2O was washed, followed by centrifugation. The number of eggs in stage 9 was estimated.

Following sterilization to determine J1 egg axenia state and viability, eggs were seeded into trypticase soy broth (TSB) and incubated for 24 to 48 h at 26 °C. After each incubation period, the number of J1 present in the media was determined and seeded into NBTA agar (0.04 g trifenyltetrazolium chloride TTC, 0.025 g bromothymol blue (BTB), 20 g nutritive agar/L) by streaking media and incubated at 26 °C for 72 h to determine Photorhabdus luminescens subsp. akhurstii SL0708 symbiont bacteria presence of or other bacteria.

Statistical analysis

A completely random assay was performed, using 10 G. mellonella larvae for each treatment and 3 replicates in time for isolation assay and hermaphrodite appearance. The independent variable corresponded to G. mellonella post-infection time 90, 95, 100, 105, 110, and 115 h, and the dependent variable to the total hermaphrodite number and egg developmental stage.

For egg and J1 isolation methodology, a completely random assay was performed including three treatments with three replicates in time. To determine the number of obtained J1 after egg sterilization, data with exposure and incubation time were compared (24 and 48 h). To facilitate axenic egg statistical analysis, the absence of bacterial growth was designated as 1, and bacterial growth in NBTA media as 2. A one-way ANOVA was performed with the significance level of 0.05%. To determine where differences occurred between groups, a Tukey post hoc test was performed, using SPSS Statistics V 24.0 (IBM, Corporation, Armonk, NY, USA).

Results and discussion

H. indica SL0708 hermaphrodite quantification and egg development characterization

The largest hermaphrodite population was obtained at 105 h (31 hermaphrodites) and 115 h (24 hermaphrodites) (Fig. 1) with significant differences post-infection (P = 0.001, df = 5, F = 16.969). Egg stage within hermaphrodite uterus isolated at 105 and 115 h corresponded to stages 6 and 8, respectively (Figs. 2 and 3f, h).

Fig. 1
figure1

Heterorhabditis indica SL0708 hermaphrodites isolated at six different post-infection time points. Significant differences (p < 0.05) among times were established by Tukey post hoc tests and are represented by different letters among times. Mean ± SEM, (n = 30)

Full size image
Fig. 2
figure2

Egg maturation stages isolated from H. indica SL0708 uterus. Significant differences (p < 0.05) among times were established by Tukey post hoc tests and are represented by different letters among times. Mean ± SEM, (n = 10)

Full size image
Fig. 3
figure3

H. indica SL0708 egg developmental stages. a Stage 1. b Stage 2. c Stage 3. d Stage 4. e Stage 5. f Stage 6. g Stage 7. h Stage 8. i Stage 9. (Scale bar = 10 μm)

Full size image

Regarding egg maturation within the hermaphrodite uterus, significant differences were observed at the six different post-infection times evaluated, with eggs at stage 9 in the vicinity of the vagina at 95 h post-infection (Figs. 2 and 3i). For the six time points, evaluated eggs were between developmental stages 5 and 9 (Fig. 2).

The nine stages of egg cleavage were observed within H. indica SL0708 uterus. For the first stage, maternal pronucleus migrated to the posterior pole, forming a pseudoclivage furrow (Fig. 3a). Subsequently, the maternal pronucleus met the paternal pronucleus and jointly migrated to the anterior pole (3B), where pronuclei fusion occurred (Fig. 3c). Forty minutes post-fertilization, first division took place forming two cells: AB and P1 (Fig. 3d). Later AB and P1 initiated their division to form 4 cells: ABa, ABp, EMS, and P2, respectively (Fig. 3e–f). Subsequent divisions occurred in the proximity of the vulva, where gastrulation took place (Fig. 3g), producing approximately 30 cells. These cells elongated and invaginated, resulting in J1 development (Fig. 3h). At 95 h post-fertilization, H. indica SL0708 J1 was observed moving within the egg (Fig. 3i).

For the six post-infection time points evaluated, in addition to observing hermaphrodites with their eggs at different stages developmental stages (1–9) (Fig. 3), individuals in Endotokia matricida were found. The greatest number of hermaphrodites was isolated at (105 and 115 h) post-infection.

The presence of hermaphrodites in Endotokia matricida have been possibly related to hermaphrodite’s incapability of laying adult eggs, since no muscular contraction of the vulva occurred, allowing for opening and egg release. Additionally, many eggs were laid at the same time, approximately 22 to 24 h post-fertilization. However, there was a time-lapse, where no egg laying occurred. Therefore, some eggs could have remained within the hermaphrodite and hatched within the uterus (Johnigk and Ehlers 1999a, b).

On the other hand, H. indica SL0708 eggs must be extracted at stage 9, given if they are extracted at earlier times the egg does not fully develop and no J1 hatches. After the eggs are fertilized, they locate themselves in the center of the uterus, where they undergo development of their first six stages. Later, they move close to the vulva, where gastrulation, morphogenesis, and J1 take place within the egg. This is a biologically relevant condition when entomopathogenic nematodes are produced in vitro. Furthermore, in some cases, not all fertilized eggs hatch, given the force vulva contraction exerts, when eggs are laid, which can result in egg rupture and J1 death (Lunau et al. 1993; Bucher and Seydoux 1994 and Johnigk and Ehlers 1999a, b).

The huge amount of hermaphrodites found at 105 and 115 h could be related to IJ invasion percentage, which was greatest at these hours (61.9 and 48.3%), respectively. Henceforth, not all IJs can enter G. mellonella larvae, and those that can achieve it at different times, even if they are exposed to the host at the same time and under the same conditions. These differences are due to signals released from the host, such as feces and CO2 that must be detected by H. indica SL0708 IJ. The IJ can then move until it localizes the host.

H. indica SL0708 hermaphrodite at 95 h post-infection had in its uterus 835 eggs (641–1116). Only 9.7% of them were in stage 9, i.e., 81 eggs (58–108) (Fig. 3i). Therefore, 81.3% were at earlier stages, before J1 was completely formed (Fig. 3). Variability in egg number and developmental stage was likely associated with uterus size and hermaphrodite physiological maturation (Han and Ehlers 1998).

In the uterus of a single H. indica SL0708 hermaphrodite, it is possible to find more than one egg developmental stage related to the process of fertilization. For fertilization to take place, first sperm has to be generated, which is stored in the receptaculum seminis. Germ cells that do not differentiate into sperm start oogenesis during the second meiotic division. Eggs mobilize from the ovotestis to the center of the uterus, going through the receptaculum seminis, where fertilization takes place. Thus, not all eggs are fertilized at the same time. Moreover, less mature eggs cannot be fertilized, since sperm is limited (Barlow et al. 2007).

H. indica SL0708 J1 axenic viable egg isolation

After performing hermaphrodite rupture and sterilization protocols, eggs were counted. Significant differences for viable J1 s were observed among treatments with 0.1 M NaOH and 1% NaOCl (P = 0.001, df = 2 F = 9.515) and incubation times (P = 0.001, df = 1, F = 16.866) (Fig. 4). After 48 h of egg incubation, the largest number of J1 was obtained at 10 min (598 J1 s), followed by 15 min (582 J1s) of exposure. Hatching percentage ranged between 23.9 and 24.6% of total eggs obtained from 30 H. indica SL0708 hermaphrodites at 95 h post-infection.

Fig. 4
figure4

Viable H. indica SL078 J1 s quantification. Significant differences among J1s at three exposure times (lowercase letters) and two incubation times (uppercase letters) were established by Tukey post hoc tests (p < 0.05). Mean ± SEM (n = 30)

Full size image

Hermaphrodite rupture and egg sterilization were achieved since NaOH hydrolyses collagen. On the other hand, NaOCl breaks down sulfhydryl bonds in the cuticle, responsible for stabilization and resistance. In addition, it eliminates bacteria associated with the chorion of the egg, since it is an alkaline solution and disrupts bacterial cytoplasmic membrane stability. Furthermore, it inhibits enzyme activity associated with trans-membrane proteins, resulting in biosynthesis alterations and phospholipid degradation (Lee 1966; Estrella et al. 2002 and Quintero and Zapata 2017).

Regarding bacterial growth, significant differences were observed for the three exposure times evaluated (P = 0.008, df = 2; F = 5.133). However, no differences were detected for incubation time (P = 0.110, df = 1, F = 2.619). The least growth for P. luminescens subsp. akhurstii SL0708 was determined at 15 min. Therefore, the time with the most viable and axenic J1 was at 15 min treatment with 0.1 M NaOH and 1% NaOCl solution, evidenced in TSA media.

Conclusions

According to the obtained results with H. indica SL0708 isolation, it is possible to isolate the most numbers of hermaphrodites with eggs at stage 9 at 95 h post-infection. However, not all hermaphrodites present the same number of eggs or stage of maturation within the uterus. Evidencing nine stages of embryonic development until it reaches J1 stage. In addition, hermaphrodite exposure to 0.1 M NaOH and 1% NaOCl solution allowed to obtain axenic and viable eggs, which can facilitate laboratory assays, where the nematode is required free from P. luminescens subsp. akhurstii SL0708 or other associated bacteria.
