Molecular identification and pathogenicity of Phytophthora nicotianae-caused bud rot disease of Washingtonia palms in Saudi Arabia and use of Lysobacter enzymogenes as a bioagent in an in vitro study
Egyptian Journal of Biological Pest Control volume 29, Article number: 3 (2019)
Severe terminal bud rot disease symptoms of Washingtonia, Washingtonia robusta, palms were observed in the 5-year-old trees in a farm located at the north of Al Shehia governorate, Qassim region, Saudi Arabia. The fungus found associated with the diseased palm buds was isolated in the laboratory, and pathogenicity tests were conducted on healthy 1-year-old Washingtonia palms, at an experimental station, Agriculture and Veterinary Medicine. Pathogenicity tests showed that a single fungus caused typical symptoms of bud rot on the inoculated trees. Petiole bases and terminal buds were rotted after 5–6 weeks of inoculation. The pathogen was identified through microscopy and characterized molecularly, using internal transcribed spacer (ITS) regions of ribosomal DNA, as a fungal-like organism Phytophthora nicotianae (synonym = P. parasitica). Experiments were conducted on the biological control of the pathogen in the laboratory, and a promising RN13 isolate of Lysobacter enzymogenes was selected for further study. This study seems to be the first report of bud rot disease of Washingtonian palms caused by P. nicotianae in Saudi Arabia. Great attention should be given to this disease because it is soil borne and may be transmitted to the date palm crop.
Mexican Washingtonian trees, Washingtonia robusta, are a member of the family Arecaceae, which is native to Northwestern Mexico. It is one of the most regularly planted palm trees around the world as an ornamental plant (Broschat 2018). Although considered a desert palm, it is native to regions having permanent surface or subsurface water (Broschat 2018). A disorder resulting in the death of 4–5-year-old W. roubsta palms in a farm north of Al Shehia district, Al Qassim region, Saudi Arabia, was brought to our attention in March 2015. Many fungal species have been reported to cause bud roots in palm trees, including Botryodiplodia, Chalara (Thielaviopsis), Colletotrichum, and Fuasrium. Phytophthora species, oomycetes, also caused various diseases on various palms including seedling blights and damping off, trunk and leaf spots, crown and root rots, blights and petiole rots; nut drop; and apical, bud, or heart rot, followed by plant death (Garofalo and McMillan 1999). About 59 identified species of Phytophthora are known as pathogens causing disease in roots, crowns, stems, leaves, and fruits of a wide range of agricultural plant species (Erwin and Ribeiro 1996). Phytophthora is a soil-borne fungus-like organism from the water mold group (Ho 2018). Phytophthora bud rot is one of the most common diseases detected in palms in wet tropical climates (Garofalo and McMillan 1999). Phytophthora nicotianae (synonym = P. parasitica) has been reported to infect ornamental palms, more than 301 different ornamental plants and vegetable hosts such as onion, Allium cepa; carnation, Dianthus caryophillus; tomato, Lycopersicum esculentum; and poinsettia, uphorbia pulcherrima. It was recently reported to infect dwarf fan palm, Chamaero pshumilis, in Iran and Italy (Faedda et al. 2011 and Nazerian and Mirabolfathi 2013). Several Lysobacter spp. including L. enzymogenes, L. antibioticus, and L. capsici (Hayward et al. 2010) reported to have the potential as one of the biological control agents for plant diseases. 3.1T8 and OH11 strains of L. enzymogenes were very effective in inhibiting the mycelial growth of Phytophthora capsici, Pythium ultimum, Py. aphanidermatum, Rhizoctonia solani, Fusarium graminearum, Ralstonia solanacearum, and Sclerotinia sclerotiorum (Christensen & Cook, 1978, Folman et al. 2003, Jiang et al. 2005, and Qian et al. 2009).
The objective of this research was to survey the bud rot disease of Washingtonia palms caused by P. nicotianae and the isolation and identification by molecular methods based on sequencing of internal transcribed spacer (ITS) regions and to suggest a method for disease control.
Materials and methods
Sample collection and pathogen isolation
Three samples from symptomatic Mexican Washingtonian trees, W. robusta, displaying a dark brown rot on the petiole base and blight of the unopened spear leaves, were collected from Al-Salamah Farm in Alshehia district, Qassim region, Saudi Arabia. Symptomatic tissue was cut into small pieces (3 × 5 mm) and surface sterilized in 10% Clorox (NaOCl 0.5%) for 30 s, rinsed twice in a sterile distilled water, and blot dried on sterilized filter papers. Sterilized tissue was placed onto potato dextrose agar (CM0139, Oxoid, 39 g/L). Three pure cultures of fungi were obtained using mycelia tip culture after incubation at 25 °C for 5 days. Representative colonies of Phytophthora spp. were sub-cultured on V8 media (10%) according to Jeffers (2006), and the pure cultures were stored on corn meal agar in 8-ml glass vials at 15 °C in the dark.
Pathogenicity of Phytophthora spp. isolates
Pathogenicity tests were performed by wound inoculation with a cork borer of ten 1-year-old potted Washingtonian trees obtained from Qassim Baladiah nursery. After disinfection of the inoculation surface with ethyl alcohol (70%), a mycelial plug (5 mm diameter) of 7-day-old colonies of the pathogen grown on V8 media (10%) was inserted into the basal stem. Then, the hole was covered with the detached tissue and wrapped with Parafilm. All plants were incubated inside the humidity chamber at 24 ± 1 °C for 48 h with 100% relative humidity (RH) then transferred into the greenhouse at 25 ± 2 °C and 43% RH for 6 weeks (Faedda et al. 2011). A set of ten trees were inoculated for each isolate as well as for the untreated control. Plants were irrigated every 2 days with a tap water. The experiment was performed at the Agriculture and Veterinary Medicine Faculty Station in 2016.
Identification of the causal pathogen
Microscopic slide cultures were prepared periodically from the isolated fungi, and their hyphal and reproductive structures were examined, measured, and photographed by an Olympus light microscope (BX51TF, Japan).
The mycelium of three samples of P. nicotianae, Qassim isolates (Phyto1, Phyto2, and Phyto3), was harvested from the surface of 7-day-old potato dextrose agar plate cultures. One hundred milligrams of mycelial mate was grounded in liquid nitrogen and used for the extraction of total genomic DNA, using i-genomic plant DNA Extraction Mini Kit (iNtRON Biotechnology, Inc., Cat. No. 17371), following the manufacturer’s instructions. The DNA was stored at − 20 °C.
Condition and amplification of PCR
Internal transcribed spacer (ITS) region amplification of rDNA was conducted in an automated thermal cycler (Swift TMMax Pro Thermal Cycler, ESCO healthcare), using ITS4/ITS5 primers (White et al. 1990). The PCR program used was 35 cycles of 94 °C for 30 s, 51 °C for 1 min, 72 °C for 1.5 min, and a final extension at 72 °C for 3 min. PCR mixture of 25 μl was as follows: 1 μl of 40 ng nucleic acid, 12.5 μl of GoTag®Colorless Master Mix (Promega Corporation, USA), 1 μl of each primer (10 pmol), and 9.5 μl of nuclease-free water (Promega). The amplified PCR products were electrophoresed for analysis through a 1.5% agarose gel containing 3 μl of ethidium bromide (10 mg/ml, Bio-Rad), and DNA bands were visualized using a UV transilluminator (G:BOXF3 system, Syngene).
The PCR products were purified, using QIA quick Gel Extraction Kit (Qiagen Inc., Chatsworth, California), and sent to Macrogen Inc. (Korea) for sequencing. The bands were sequenced in two directions with ITS4/ITS5 primers (White et al. 1990). Raw sequence chromatograms were gathered and modified, using GAP4 (Bonfield et al. 1995). Homologies to known sequences were identified, using the BLASTN algorithms (Altschul et al. 1997) compared to the redundant GenBank database at https://blast.ncbi.nlm.nih.gov/Blast.cgi. ClustalW was used for multiple alignments of sequences (Thompson et al. 1994), and the maximum parsimony method, using MEGA4 software, was used to draw the phylogenetic analyses (Tamura et al. 2007). The ITS4/ITS5 sequences of different Phytophthora species from several countries, used for comparisons, were retrieved from GenBank (www.ncbi.nlm.nih.gov).
L. enzymogenes was selected among 20 other bacterial isolates from the previous study of Abdullah et al. (2016). This isolate was known as the best biocontrol agent against many plants pathogenic fungi compared to other tested isolates and coded RN13. This bacterium was identified by 16S rDNA as L. enzymogenes BB14 with 99% similarity percent, using BLAST (Abdullah et al. 2016).
In vitro antifungal activity
An overnight-grown bacterial culture was streaked as a circle shape on V8 media (10%) plate). A disk of P. nicotianae (phyto1 isolate) was placed in the middle of a bacterial circle and incubated at 25 °C for 7 days. V8 media (10%) plate was inoculated by fungus only as a control. The inhibition percent was recorded by measuring a growth diameter in treatment and control after the incubation period by following the formula according to Naureen et al. (2009): inhibition percentage = (diameter in control − diameter in treatment/diameter in control) × 100.
Results and discussion
Symptoms of the disease in the field
The diseased palms were individually scattered in the field, and the visual percentage of infected or dead palms was 3–5%. Symptomatology of the disease in the field included wilting of the youngest leaves, first manifested as a change in the leaf color to a paler green that progressed to a green brown and eventually to light brown as the leaves became desiccated and wilted (Figs. 1 and 2), and when making a cross section at the base of the diseased palm, the bases of the petioles show brown to dark brown soft tissues with a foul smell (Fig. 2). Progressive separation of the petiole bases of diseased palms showed tan-colored necrotic lesions, with brown margins. The surface of some lesions was covered by layers of white mycelia (Fig. 2). At the late stages of the disease, pale leaves completely died, buds were totally rotted, and leaf petioles disintegrated leaving a black cavity in the base of the dead palm (Fig. 3). Making a transverse section of a diseased tree at the petiole showed a brown discoloration and rot at the base and terminal bud tissues (Fig. 3). Bud (heart) rot in palm trees are caused by many species of Phytophthora in the world. P. nicotianae has been reported to infect blue Mediterranean fan palm (Chamaerops humilis var. argenta), causing basal leaf rot in Iran (Nazerian and Mirabolfathi 2013), in North America (Bomberger et al. 2016), and in Italy (Faedda et al. 2011). Therefore, bamboo palm, Chamaedorea erumpens; reed palm, C. seifrizii; Macarthur palm, Ptychosperma macarthurii; red sealing wax palm, Cyrtosta chysrenda; thatch palm, Thrinax sp.; and Mexican fan palm, W. robusta have been reported infected by P. nicotianae with stem, leaf, and root rots (Elliott et al. 2004). P. palmivora attacked W. robusta and W. filifera, causing one bud rot.
All the three Phytophthora isolates (Phyto1, Phyto2, and Phyto3) were highly pathogenic to W. robusta young trees. Infected plants were pale, weathered, and growing poorly compared to inoculated plants 3 weeks after inoculation. The inoculated plants were almost dead at the fifth week compared to inoculated check plants (Fig. 4). When infected trees were longitudinally split by a sharp knife after 5–6 weeks from inoculation, the terminal bud and petiole bases were totally decayed showing brown to black rotted tissues (Fig. 5). Isolation from the dead and diseased tissues of the artificially inoculated trees revealed that all the tissues were infected with the same pathogen that was used for their inoculation.
The three isolated fungi were identical in their morphological characteristics. The pathogen was identified as P. nicotianae that was characterized by thick and branched hyphal growth (5–7.1 μm). Zoosporangia (30.36–43.97 μm) were formed on the mycelium 3–4 days after an incubation at 28 °C (Fig. 6a). Thickly walled sporangiospores (59.18–68.42 μm) were formed extensively on the mycelium in 7–15-day-old cultures (Fig. 6b). Sporangia were formed 3–4 days after an incubation at 28 °C and an extensive formation of chlamidospores was observed in culture plates of 7–15 days old. The results presented above are characteristics of P. nicotianae based on previous studies reported by Stamps et al. (1990) and Faedda et al. (2011). Traditionally, Phytophthora species taxonomic identification has been based upon microscopic examination of morphological characters and cultural criteria (Stamps et al. 1990).
P. nicotianae causes seedling blight of golden palm and also attacks California fan palm, causing trunk and collar rots. The disease appears to begin from wounds caused by leaf removal at or near the soil line. Although this disease can be reproduced by inoculations of the lower trunk, the bud and the entire stem are eventually rotted on some plants. Thus, P. nicotianae should also be considered as a possible cause of bud rots.
Molecular characterization of P. nicotianae isolates
A band of about 900 bp was amplified using total DNA from the three isolates (phyto1, phyto2, and phyto3) of P. nicotianae using the universal ITS4/ITS5 primers (Fig. 7). The three PCR products were sequenced obtaining for phyto1, phyto2, and phyto3 881, 843, and 843 bp, respectively. ITS region was conventionally used for the molecular identification of plant pathogenic fungi (Durán et al. 2010). The fungal ITS region varies between approximately 450 and 750 bp in length and consists of the variable spacers ITS1 and ITS2 and the intercalary 5.8S gene (Schoch et al. 2012). The ITS region sequences of P. nicotianae isolates were compared by other ITS sequences of Phytophthora species reported in GenBank (www.ncbi.nlm.nih.gov). The phylogenetic results (Fig. 8) revealed that the Phytophthora isolates formed two clades (I and II). Clade I includes the three P. nicotianae isolates from Qassim region and all P. nicotianae and P. parasitica isolates. However, the three P. nicotianae isolates from Qassim region have been separated and formed subclade B with P. nicotianae isolate 2013CAP2002 (KJ549640) from the USA and P. nicotianae strain IIFT 155 (GU073389) from Cuba with 100% of the identity confirming genetic similarity of isolates (Fig. 8). P. palmivora strains were distanced from other Phytophthora isolates by bootstrap 100% and grouped together in clade II. The Qassim P. nicotianae isolates had more than (99.6%) nucleotide identity with P. nicotianae and P. parasitica isolates, whereas the identities were less than (89.3%) with all P. palmivora strains. An analysis of nucleotide sequences of internal transcribed spacer (ITS) regions of rDNA has been used to differentiate Phytophthora species (Cooke et al. 2000, Förster et al. 2000, and Meenupriya and Thangaraj 2011). Also, the ITS could be successfully used for discriminating closely related species of a broad range of fungi (Schoch et al. 2012).
As shown in Fig. 9, the growth of P. nicotianae (Phyto1 isolate) was more inhibited by using the bacterial strain L. enzymogenes BB14 than in the control treatment. The tested bacterial isolate exhibited stronger inhibitory effects on mycelial growth of P. nicotianae after 7 days, nearly 100% inhibition percentage. The potential biological control for plant diseases has been recently reported, using Lysobacter species (Folman et al. 2003 and Sullivan et al. 2003). Li et al. (2008) reported that L. enzymogenes strain C3 is a biological control agent that has a strong antagonist effect against several fungal pathogens. L. enzymogenes has been reported to suppress soil-borne diseases, such as Rhizoctonia solani that caused brown patch in turf grass (Giesler and Yuen 1998). Moreover, L. enzymogenes has been cited to control foliar diseases, for example, Bipolaris sorokiniana causal agent of leaf spot of tall fescue (Zhang and Yuen 1999), Uromyces appendiculatus causal agent of bean rust (Yuen et al. 2001), and Fusarium head blight of wheat (Jochum et al. 2006).
In this study, the bacterial isolate L. enzymogenes BB14 was more active in chitin hydrolysis as shown in Fig. 10 which gives it more antifungal activity against P. nicotianae. Li et al. (2008) mentioned that the antifungal activity of L. enzymogenes was attributed in part to lytic enzymes. Many extracellular enzymes that contribute to biocontrol activity, including multiple forms of β-1, 3-glucanases, and chitinases, are produced by L. enzymogenes as reported by Zhang et al. (2001) and Palumbo et al. (2005).
Terminal bud rot of W. robusta observed in Al Qassim region, caused by P. nicotianae, is a pathogenic disease that could be transmitted to other crops through infected soil and irrigation water as well as farming tools. The pathogen is similar in morphology and disease symptoms to P. palmivora, but the sequencing analyses of internal ITS regions of ribosomal DNA confirmed that the causal agent was P. nicotianae. Experiments on the biological control of the disease showed that the bacterial strain L. enzymogenes was a potential antagonist to P. nicotianae on V8 media (10%) Petri plates. However, further studies are needed on the control of the disease and susceptible plant species both in the laboratory and in the field.
Abdullah RR, Sukar NA, Alsohim AS (2016) Detection of Chi gene in chitinolytic soil born bacteria and their efficiency as a bio-insecticide against Tuta absoluta (Lepidoptera: Gelechiidae). J Agric Vet Sci 9:107–117
Altschul SF, Madden TL, Schäffer AA, Zhang J, Zhang Z, Miller W, Lipman DJ (1997) Gapped BLAST (Basic Local Alignment Search Tool) and PSI-BLAST: a new generation of protein database search programs. Nucleic Acids Res 25:3389–3402
Bomberger RA, Duranovic X, Wang S (2016) First report of basal petiole rot and leaf blight caused by Phytophthora nicotianae on Chamaerops humilis in North America. Plant Dis 100:212
Bonfield JK, Smith KF, Staden R (1995) A new DNA sequence assembly program. Nucleic Acids Res 24:4992–4999
Broschat, T.K. 2018. Washingtonia robusta: Mexican fan palm. ENH-827. Environmental Horticulture Department, UF/IFAS Extension. http://edis.ifas.ufl.edu/st670
Christensen P, Cook FD (1978) Lysobacter, a new genus of nonfruiting, gliding bacteria with a high base ratio. Int J Syst Bacteriol 28:367–393
Cooke DEL, Drenth A, Duncan JM, Wagels G, Brasier CM (2000) A molecular phylogeny of Phytophthora and related oomycetes. Fung Genet Biol 30:17–32
Durán A, Gryzenhout M, Drenth A, Slippers B, Ahumada R, Wingfield BD, Wingfield MJ (2010) AFLP analysis reveals a clonal population of Phytophthora pinifoliain Chile. Fungal Biolo. 114:746–752
Elliott ML, Broschat TK, Uchida JY, Simone GW (2004) Diseases and disorders of ornamental palms. American Phyto-pathological Society, St. Paul
Erwin DC, Ribeiro OK (1996) Phytophthora diseases worldwide. APS press, St. Paul, p 562
Faedda R, Pane A, Granata G, San Lio GD (2011) First report of Phytophthora nicotianae as pathogen of blue Mediterranean fan palm. New Dis Rep. 23:3
Folman LB, Postma J, van Veen JA (2003) Characterization of Lysobacter enzymogenes (Christensen and Cook 1978) strain 3.1T8, a powerful antagonist of fungal diseases of cucumber. Microbiol Res 158:107–115
Förster H, Cummings MP, Coffey MD (2000) Phylogenetic relationships of Phytophthora species based on ribosomal ITS I DNA sequence analysis with emphasis on Waterhouse groups V and VI. Mycol Res 104:1055–1061
Garofalo JF, McMillan RT (1999) Phytophthora bud-rot of palms in South Florida. Proc Fla State Hort Soc 112:110–112
Giesler LJ, Yuen GY (1998) Evaluation of Stenotrophomonas maltophilia strain C3 for biocontrol of brown patch disease. Crop Prot 17:509–513
Hayward AC, Fegan N, Fegan M, Stirling GR (2010) Stenotrophomonas and Lysobacter: ubiquitous plant-associated gamma-proteobacteria of developing significance in applied microbiology. J Appl Microbiol 108:756–770
Ho HH (2018) The taxonomy and biology of Phytophthora and Pythium. J Bacteriol Mycol Open Access 6:40–45. https://doi.org/10.15406/jbmoa.2018.06.00174
Jeffers SN (2006) Identifying species of Phytophthora. Clemson University, Clemson
Jiang YH, Hu BS, Liu FQ (2005) Selection and identification of antagonistic bacteria against soil-borne plant pathogens. Chinese Journal of Biological Control 21:260–264
Jochum CC, Osborne LE, Yuen GY (2006) Fusarium head blight biological control with Lysobacter enzymogenes. Biol Control. 39:336–344
Li S, Jochum CC, Yu F, Zaleta-Rivera K, Du L, Harris SD, Yuen GY (2008) An antibiotic complex from Lysobacter enzymogenes strain C3: antimicrobial activity and role in plant disease control. Phytopathology 98:695–701
Meenupriya J, Thangaraj M (2011) Analytical characterization and structure elucidation of metabolites from Aspergillus ochraceus MP2 fungi. Asian Pac J Trop Biomed 5:376–380
Naureen Z, Price AH, Hafeez FY, Roberts MR (2009) Identification of rice blast disease-suppressing bacterial strains from the rhizosphere of rice grown in Pakistan. Crop Prot. 28:1052–1060
Nazerian E, Mirabolfathi M (2013) Characterization of Phytophthora nicotianae pathogenic to Chamaerops humilis in Iran. Int J Agric For 3:159
Palumbo JD, Yuen GY, Jochum CC, Tatum K, Kobayashi DY (2005) Mutagenesis of β-1,3-glucanase genes in Lysobacter enzymogenes strain C3 results in reduced biological control activity toward Bipolaris leaf spot of tall fescue and Pythium damping-off of sugar beet. Phytopathol. 95:701–707
Qian GL, Hu BS, Jiang YH, Liu FQ (2009) Identification and characterization of Lysobacter enzymogenes as a biological control agent against some fungal pathogens. Agric Sci China 8:68–75
Schoch CL, Seifert KA, Huhndorf S, Robert V, Spouge JL, Levesque CA, Chen W, Fungal Barcoding Consortium (2012) Nuclear ribosomal internal transcribed spacer (ITS) region as a universal DNA barcode marker for Fungi. PNAS 109:6241–6246
Stamps DJ, Waterhouse GM, Newhook FJ, Hall GS (1990) Revised tabular key to the species of Phytophthora. Mycology papers no. 162. C.A.B International Mycological Institute, Egham
Sullivan RF, Holtman MA, Zylstra GJ, White JF, Kobayashi DY (2003) Taxonomic positioning of two biological control agents for plant diseases as Lysobacter enzymogenes based on phylogenetic analysis of 16S rDNA, fatty acid composition and phenotypic characteristics. J Appl Microbiol 94:1079–1086
Tamura K, Dudley J, Nei M, Kumar S (2007) MEGA4: molecular evolutionary genetics analysis (MEGA) software version 4.0. Mol Biol Evol 24:1596–1599
Thompson JD, Higgins DG, Gibson TJ (1994) CLUSTAL W: improving the sensitivity of progressive multiple sequence alignment through sequence weighting, position-specific gap penalties and weight matrix choice. Nucleic Acids Res 22:4673–4680
White TJ, Bruns T, Lee S, Taylor J (1990) Amplification and direct sequencing of fungal ribosomal RNA genes for phylogenetics. In: Innis MA, Gelfand DH, Sninsky JJ, White TJ (eds) PCR protocols: a guide to methods and applications. Academic Press, New York, pp 315–322
Yuen GY, Steadman JR, Lindgren DT, Schaff D, Jochum C (2001) Bean rust biological control using bacterial agents. Crop Prot 20:395–402
Zhang Z, Yuen GY (1999) Biological control of Bipolari sorakiniana on tall fescue by Stenotrophomona smaltophilia strain C3. Phytopathology 89:817–822
Zhang Z, Yuen GY, Sarath G, Penheiter AR (2001) Chitinases from the plant disease biocontrol agent, Stenotrophomona smaltophilia C3. Phytopathology 91:204–211
The authors would like to thank Dr. Edel Pérez-López (Department of Biology, University of Saskatchewan, Saskatoon, Saskatchewan, Canada) for critical revision of manuscript and editing English.
Availability of data and materials
The data that support the findings of this study are available are available from the corresponding author on reasonable request.
Ethics approval and consent to participate
Consent for publication
We give our consent for the publication in Egyptian Journal of Biological pest Control.
The authors declare that they have no competing interests.
